Product Details:
|
| Warranty: | 1year | Rated Voltage: | 110V-480V |
|---|---|---|---|
| Rated Current: | 20A To 7000A | Speed: | 1500 Rmp / 1800 Rmp |
| Frequency: | 50 Hz/ 60 Hz | Starting System: | 24V DC Electric Start |
| Type: | Mobile Type | Weight: | 2750KG |
| Cooling System Type: | Water Cooling System | Engine Model: | YC6B205L-D20 |
| Alternator: | MP-A-165 | Rated Power: | 132KW/165KVA |
| Phase: | 3 | Engine Brand: | Yuchai Brand |
| Engine Cylinder: | 6/L | Noise: | 72dB(A) |
| Delivery Port: | Guangxi | Output Type: | AC Three Phase 220/380V 50/60Hz |
| Fuel: | 0#or-10# Light Diesel Oil |
|
Diesel generaor
|
value
|
|
|
Model
|
MP-Y165
|
|
|
Power
|
132KW/165KVA
|
|
|
Frequency
|
50HZ
|
|
|
Voltage
|
400V
|
|
|
Optional type
|
Open type/Silent
|
|
|
Size of open type
|
3000*1950*2700mm
|
|
|
Weight of open type
|
2750kg
|
|
|
Engine
|
|
|
|
Model
|
Yuchai YC6B205L-D20
|
|
|
Cylinder
|
6L Arrangement
|
|
|
Bore*Stroke
|
108mm*125mm
|
|
|
Displacement
|
6.87L
|
|
|
Fuel consumption
|
203g/kw.h
|
|
|
Speed governor
|
Electronic
|
|
|
Alternator
|
|
|
|
Optional brand
|
Stamford/Leroy Somer/Mecc Alte/Marathon
|
|
|
Exciter type
|
Single bearing,brushless,Self-excited
|
|
|
Power factor
|
0.8
|
|
|
Voltage adjust
|
≥5%
|
|
|
Insulation
|
H
|
|
|
Protection grade
|
IP23
|
|
|
Controller
|
|
|
|
Option brand
|
Deepsea/Deif/ComAp/Smartgen
|
|
