Product Details:
|
| Warranty: | 1year | Rated Voltage: | 110V-480V |
|---|---|---|---|
| Rated Current: | 20A To 7000A | Speed: | 1500 Rmp / 1800 Rmp |
| Frequency: | 50 Hz/ 60 Hz | Weight: | 1950KG |
| Engine Model: | TAD531GE | Alternator: | MP-A-90 |
| Rated Power: | 90KW/112.5KVA | Phase: | 3 |
| Engine Brand: | Volvo Brand | Engine Cylinder: | 4/L |
| Noise: | 72dB(A) | Delivery Port: | Sweden |
| Output Type: | AC Three Phase 220/380V 50/60Hz | Fuel: | 0#or-10# Light Diesel Oil |
| Port: | Shanghai |
Diesel generaor | value | |
Model | MP-C90 | |
Power | 90KW/112.5KVA | |
Frequency | 50HZ | |
Voltage | 400V | |
Optional type | Open type/Silent | |
Size of open type | 3000*1240*1760mm | |
Weight of open type | 1950kg | |
Engine | ||
Model | Volvo TAD531GE | |
Cylinder | 4L Arrangement | |
Bore*Stroke | 108mm*130mm | |
Displacement | 4.76L | |
Fuel consumption | 214g/kw.h | |
Speed governor | Machinery | |
Alternator | ||
Optional brand | Stamford/Leroy Somer/Mecc Alte/Marathon | |
Exciter type | Single bearing,brushless,Self-excited | |
Power factor | 0.8 | |
Voltage adjust | ≥5% | |
Insulation | H | |
Protection grade | IP23 | |
Controller | ||
Option brand | Deepsea/Deif/ComAp/Smartgen | |
